40kW Movable Charger

The Kempower Movable Charger is the stand-alone, mobile solution for fast DC charging of all types of electric vehicles.

The Movable Charger can be used anywhere, including events, bus & truck depots, logistics centers, car service shops, and other locations where fast charging is needed. The only requirement for using the plug-and-play Movable Charger is a 63 A or 32 A mains socket.

The Movable Charger can have one or two DC charging outputs, with CCS2 and CHAdeMo as options. The available charging power is automatically distributed between the charging outputs. There are two output voltage levels: 400 VDC and 800 VDC.

For charging wherever, whenever.

movable charger iconmovable charger icon
Movable Charger for easy use wherever needed
on screen qr code iconon screen qr code icon
On-screen QR code for following the charging status on your mobile phone
plug and play iconplug and play icon
Plug & play, easy to commission & use
removable wheels iconremovable wheels icon
Removable wheels for fixed installation
charging control iconcharging control icon
Advanced charging control and customization with Kempower ChargEye
stand alone charging iconstand alone charging icon
Stand-alone charging system
40kw movable charger infographic

Technical Specifications

Electrical Specs
Grid connection (AC) 3P+PE
Grid supply connector IEC 60309
Supply cable length 5 m
Input nominal voltage 400 VAC
Input operating voltage 380…480 VAC +6%/-10%
Input frequency 50…60 Hz
Nominal input power 47 kVA (at nominal input voltage)
Power factor at full load 0.92
Efficiency at full load 94%
Idle power 20 VA
Overvoltage category III
Rated conditional short-circuit current 25 kA
Network type TN-S, TN-C, TN-C-S, TT

General and Environmental Specs
Operating temperature 30…+50 °C
Current derating Charging current decreases 1.5% for every 1 °C rise in temperature above +40 °C
Maximum altitude without derating 2000 m
Altitude derating Charging current decreases 1.4% for every 100 m rise above 2000 m
Operational noise level > 60 dB at 1 m distance
Storage temperature 40…+60 °C
Ambient air humidity > 95% relative humidity
Enclosure rating IP54, IK10
Overall dimensions [ W x H x D ] 638 x 1216 x 670
Weight [ Kg ] 1 charging cable: 140–150, 2 charging cables: 160–180

Connections and Protocols
WiFi 802.11 b/g/n (2.4/5 GHz)
Cellular/GPS LTE-FDD, LTE-TDD, WCDMA, GSM
Ethernet RJ45, IEEE 802.3/802.3u
OCPP 1.6j/2.0.1
Connectivity Kempower ChargEye solution
CCS2 DIN 70121:2012, ISO 15118:2013, ISO 15118:2010
CHAdeMO 0.9/1.0

DC Charging Output
T500 T800
Nominal output power at 400 VAC 40 kW (with 2 outputs: Dynamic 40 kW one output or 20 kW per output) at 400 VDC 40 kW (with 2 outputs: Dynamic 40 kW one output or 20 kW per output) at 667 VDC
Nominal output current 2 x 50 A, 1 x 100 A 2 x 30 A, 1 x 60 A
Output voltage range 150…500 VDC 200…920 VDC
